TPS2838PWP دیتاشیت

TPS2838PWP

مشخصات دیتاشیت

نام دیتاشیت TPS2838PWP
حجم فایل 101.641 کیلوبایت
نوع فایل pdf
تعداد صفحات 24

دانلود دیتاشیت TPS2838PWP

دانلود دیتاشیت

سایر مستندات

TPS2838-39/48-49 23 pages

مشخصات فنی

  • RoHS: true
  • Category: Power Supply Chip/Gate Drive ICs
  • Datasheet: Texas Instruments TPS2838PWP
  • Fall Time: 65ns
  • Load Type: MOSFET
  • Rise Time: 65ns
  • Supply Voltage: 10V~15V
  • Number of Drivers: 2
  • Driven Configuration: Half Bridge
  • Operating Temperature: -40°C~+125°C@(Tj)
  • Peak Output Current(sink): 4A
  • Peak Output Current(source): 4A
  • Package: TSSOP-16-EP
  • Manufacturer: Texas Instruments
  • Series: -
  • Package / Case: 16-PowerTSSOP (0.173", 4.40mm Width)
  • Current - Peak Output (Source, Sink): 4A, 4A
  • Base Part Number: TPS283
  • Channel Type: Synchronous
  • Rise / Fall Time (Typ): 65ns, 65ns
  • Part Status: Active
  • Mounting Type: Surface Mount
  • Logic Voltage - VIL, VIH: 1V, 2V
  • Gate Type: N-Channel MOSFET
  • Voltage - Supply: 10V ~ 15V
  • Packaging: Tube
  • Input Type: Non-Inverting
  • Supplier Device Package: 16-HTSSOP
  • High Side Voltage - Max (Bootstrap): 29V
  • detail: Half-Bridge Gate Driver IC Non-Inverting 16-HTSSOP
