CC2545RGZR دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
CC2545RGZR
|
|
حجم فایل
|
82.104
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
32
|
مشخصات فنی
-
RoHS:
true
-
Category:
Radio Frequency Chip/Antenna/RF Transceiver ICs
-
Data Rate:
2Mbps
-
Datasheet:
Texas Instruments CC2545RGZR
-
Interface:
I2C,SPI,USART
-
Applications:
General-purpose ISM>1GHz
-
Frequency Range:
2.4GHz
-
Receive Current:
20.8mA
-
Operating Voltage:
2V~3.6V
-
Operating Temperature:
-40°C~+85°C
-
Current Of Transmitting:
26.3mA
-
Package:
QFN-48-EP(7x7)
-
Manufacturer:
Texas Instruments
-
Type:
TxRx + MCU
-
Sensitivity:
-98dBm
-
Base Part Number:
CC2545
-
Current - Transmitting:
26.3mA ~ 30.2mA
-
Frequency:
2.4GHz
-
Package / Case:
48-VFQFN Exposed Pad
-
Memory Size:
32kB Flash, 1kB SRAM
-
Modulation:
GFSK, MSK
-
Voltage - Supply:
2V ~ 3.6V
-
GPIO:
31
-
Series:
-
-
RF Family/Standard:
General ISM > 1GHZ
-
Protocol:
-
-
Supplier Device Package:
48-VQFN (7x7)
-
Packaging:
Cut Tape (CT)
-
Part Status:
Discontinued at Digi-Key
-
Mounting Type:
Surface Mount
-
Serial Interfaces:
I²C, SPI, USART
-
Power - Output:
5dBm
-
Data Rate (Max):
2Mbps
-
Current - Receiving:
20.8mA
-
detail:
IC RF TxRx + MCU General ISM > 1GHZ 2.4GHz 48-VFQFN Exposed Pad
