ADDAC80NZ-CBI-V Datasheet

ADDAC80NZ-CBI-V

Datasheet specifications

Datasheet's name ADDAC80NZ-CBI-V
File size 121.609 KB
File type pdf
Number of pages 16

Download Datasheet ADDAC80NZ-CBI-V

Download Datasheet

Other documentations

ADDAC80/85/87 16 pages

Technical specifications

  • RoHS: true
  • Category: ADC/DAC/Data Conversion/Digital To Analog Converters (DACs)
  • Datasheet: Analog Devices ADDAC80NZ-CBI-V
  • Interface: Parallel
  • Resolution: 12Bit
  • Output Type: Voltage-缓冲
  • Settling Time: 4us
  • Supply Voltage: 4.5V~16V
  • Integral nonlinearity: ±0.25LSB;±0.75LSB
  • Operating Temperature: -25°C~+85°C
  • Package: PDIP-24
  • Manufacturer: Analog Devices
  • Series: -
  • Packaging: Tube
  • Part Status: Active
  • Number of Bits: 12
  • Number of D/A Converters: 1
  • Differential Output: No
  • Data Interface: Parallel
  • Reference Type: External, Internal
  • Voltage - Supply, Analog: ±11.4V ~ 16.5V
  • Voltage - Supply, Digital: 4.5V ~ 16V
  • INL/DNL (LSB): ±0.25, ±0.75 (Max)
  • Architecture: R-2R
  • Package / Case: 24-DIP (0.600", 15.24mm)
  • Supplier Device Package: 24-PDIP
  • Mounting Type: Through Hole
  • Base Part Number: ADDAC80
  • detail: 12 Bit Digital to Analog Converter 1 24-PDIP
