دیتاشیت ATTINY2313-20MUR

ATtiny2313(V) Datasheet Summary

مشخصات دیتاشیت

نام دیتاشیت ATtiny2313(V) Datasheet Summary
حجم فایل 384.728 کیلوبایت
نوع فایل pdf
تعداد صفحات 20

دانلود دیتاشیت ATtiny2313(V) Datasheet Summary

ATtiny2313(V) Datasheet Summary Datasheet

مشخصات

  • CAN: -
  • I2C: -
  • I2S: -
  • SPI: -
  • RoHS: true
  • EEPROM: 128Byte
  • CPU Core: AVR
  • Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
  • RAM Size: 128Byte
  • Watchdog: Yes
  • ADC (Bit): -
  • DAC (Bit): -
  • Datasheet: Microchip Tech ATTINY2313-20MUR
  • PWM (Bit): -
  • 8Bit Timer: -
  • UART/USART: -
  • 16Bit Timer: -
  • 32Bit Timer: -
  • Real-Time Clock: -
  • CPU Maximum Speed: 20MHz
  • GPIO Ports Number: 18
  • Low-Voltage Detect: Yes
  • CCP Capture/Compare: -
  • Internal Comparator: -
  • Internal Oscillator: Yes
  • Peripheral/Function: WDT
  • Program Memory Type: FLASH
  • Direct Memory Access: -
  • Program Storage Size: 2KB
  • Universal Serial Bus: -
  • communication protocol: -
  • Operating Voltage Range: 2.7V~5.5V
  • Infrared Data Association: -
  • Operating Temperature Range: -40°C~+85°C
  • Secure Digital Input and Output: -
  • Package: QFN-20-EP(4x4)
  • Manufacturer: Microchip Tech
  • Series: AVR® ATtiny
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Core Processor: AVR
  • Core Size: 8-Bit
  • Speed: 20MHz
  • Connectivity: SPI, UART/USART
  • Peripherals: Brown-out Detect/Reset, POR, PWM, WDT
  • Number of I/O: 18
  • Program Memory Size: 2KB (1K x 16)
  • EEPROM Size: 128 x 8
  • Voltage - Supply (Vcc/Vdd): 2.7V ~ 5.5V
  • Data Converters: -
  • Oscillator Type: Internal
  • Operating Temperature: -40°C ~ 85°C (TA)
  • Mounting Type: Surface Mount
  • Package / Case: 20-WFQFN Exposed Pad
  • Supplier Device Package: 20-QFN-EP (4x4)
  • Base Part Number: ATTINY2313
  • detail: AVR AVR® ATtiny Microcontroller IC 8-Bit 20MHz 2KB (1K x 16) FLASH 20-QFN-EP (4x4)
