ADG201HSKNZ دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت ADG201HS	دانلود دیتاشیت

مستندات دیگری یافت نشد!

RoHS: true
Category: Communication Interface Chip/UART/485/232/Analog Switches / Multiplexers
Turn-on time: 50ns
Turn-off time: 50ns
Supply Voltage: 10.8V~16.5V
Switch Circuit: SPST(SPST)-Normally closed
Number of Channels: 4
On-State Resistance (Max): 50Ω
Package: PDIP-16
Manufacturer: Analog Devices
Series: -
Packaging: Tube
Part Status: Obsolete
Multiplexer/Demultiplexer Circuit: 1:1
Number of Circuits: 4
Channel-to-Channel Matching (ΔRon): 1.5Ohm
Voltage - Supply, Single (V+): 10.8V ~ 16.5V
Voltage - Supply, Dual (V±): ±13.5V ~ 16.5V
Switch Time (Ton, Toff) (Max): 50ns, 50ns
-3db Bandwidth: -
Charge Injection: 10pC
Channel Capacitance (CS(off), CD(off)): 10pF, 10pF
Current - Leakage (IS(off)) (Max): 1nA
Crosstalk: -86dB @ 100kHz
Operating Temperature: -40°C ~ 85°C (TA)
Mounting Type: Through Hole
Package / Case: 16-DIP (0.300", 7.62mm)
Supplier Device Package: 16-PDIP
Base Part Number: ADG201
detail: 4 Circuit IC Switch 1:1 50Ohm 16-PDIP
