دیتاشیت DAC8412AT/883C
مشخصات دیتاشیت
| نام دیتاشیت |
DAC8412,13
|
| حجم فایل |
483.926
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
20
|
مشخصات
-
Manufacturer:
Analog Devices Inc.
-
Series:
-
-
Packaging:
Tube
-
Part Status:
Active
-
Number of Bits:
12
-
Number of D/A Converters:
4
-
Settling Time:
10µs (Typ)
-
Output Type:
Voltage - Buffered
-
Differential Output:
No
-
Data Interface:
Parallel
-
Reference Type:
External
-
Voltage - Supply, Analog:
5V ~ 15V
-
Voltage - Supply, Digital:
5V
-
INL/DNL (LSB):
±0.75, -1
-
Architecture:
R-2R
-
Operating Temperature:
-55°C ~ 125°C
-
Package / Case:
28-CDIP (0.600", 15.24mm)
-
Supplier Device Package:
28-CerDip
-
Mounting Type:
Through Hole
-
Notification:
QPL or Military Specs are for reference only. Parts are not for military use. See Terms and Conditions.
-
Base Part Number:
DAC8412
-
detail:
12 Bit Digital to Analog Converter 4 28-CerDip
