DAC7513E/2K5G4 数据手册
其他文档
DAC7513 27 pages
技术规格
- RoHS: true
- Category: ADC/DAC/Data Conversion/Digital To Analog Converters (DACs)
- Datasheet: Texas Instruments DAC7513E/2K5G4
- Package: VSSOP-8-0.65mm
- Manufacturer: Texas Instruments
- Series: -
- Voltage - Supply, Digital: 2.7V ~ 5.5V
- Voltage - Supply, Analog: 2.7V ~ 5.5V
- INL/DNL (LSB): ±8 (Max), ±1 (Max)
- Supplier Device Package: 8-VSSOP
- Package / Case: 8-TSSOP, 8-MSOP (0.118", 3.00mm Width)
- Number of Bits: 12
- Differential Output: No
- Part Status: Active
- Reference Type: External
- Settling Time: 10µs
- Mounting Type: Surface Mount
- Operating Temperature: -40°C ~ 105°C
- Architecture: String DAC
- Output Type: Voltage - Buffered
- Number of D/A Converters: 1
- Packaging: Tape & Reel (TR)
- Base Part Number: DAC7513
- Data Interface: SPI, DSP
- detail: 12 Bit Digital to Analog Converter 1 8-VSSOP
