دیتاشیت MCP19124-E/MJ
مشخصات دیتاشیت
| نام دیتاشیت |
MCP19124,25
|
| حجم فایل |
1982.132
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
236
|
مشخصات
-
Manufacturer:
Microchip Technology
-
Series:
Automotive, AEC-Q100
-
Packaging:
Tube
-
Part Status:
Active
-
Output Type:
PWM Signal
-
Function:
Step-Up/Step-Down
-
Output Configuration:
Positive
-
Topology:
Boost, Cuk, Flyback, SEPIC
-
Number of Outputs:
1
-
Output Phases:
2
-
Voltage - Supply (Vcc/Vdd):
4.75V ~ 5.5V
-
Frequency - Switching:
31.25kHz ~ 2MHz
-
Duty Cycle (Max):
-
-
Synchronous Rectifier:
Yes
-
Clock Sync:
Yes
-
Serial Interfaces:
I²C, PMBus, SMBus
-
Control Features:
Dead Time Control, Frequency Control, Ramp, Soft Start
-
Operating Temperature:
-40°C ~ 125°C (TJ)
-
Mounting Type:
Surface Mount
-
Package / Case:
24-VFQFN Exposed Pad
-
Supplier Device Package:
24-QFN (4x4)
-
Base Part Number:
MCP19124
-
detail:
Boost, Cuk, Flyback, SEPIC Regulator Positive Output Step-Up/Step-Down I²C, PMBus, SMBus DC-DC Controller IC 24-QFN (4x4)
