دیتاشیت TPS2236DAP

TPS2231, TPS2236

مشخصات دیتاشیت

نام دیتاشیت TPS2231, TPS2236
حجم فایل 651.594 کیلوبایت
نوع فایل pdf
تعداد صفحات 26

دانلود دیتاشیت TPS2231, TPS2236

TPS2231, TPS2236 Datasheet

مشخصات

  • RoHS: true
  • Category: Communication Interface Chip/UART/485/232/Pre-ordered Chips
  • Datasheet: Texas Instruments TPS2236DAP
  • Package: HTSSOP-32-EP-6.1mm
  • Manufacturer: Texas Instruments
  • Number of Outputs: 6
  • Voltage - Supply (Vcc/Vdd): Not Required
  • Base Part Number: TPS223
  • Operating Temperature: -40°C ~ 85°C (TA)
  • Package / Case: 32-PowerTSSOP (0.240", 6.10mm Width)
  • Ratio - Input:Output: 1:2
  • Current - Output (Max): 1.3A
  • Voltage - Load: 1.5V, 3.3V
  • Series: -
  • Rds On (Typ): 45mOhm
  • Supplier Device Package: 32-HTSSOP
  • Fault Protection: Current Limiting (Fixed), Over Temperature
  • Output Configuration: High Side
  • Part Status: Active
  • Mounting Type: Surface Mount
  • Interface: -
  • Switch Type: ExpressCard™ Switch
  • Packaging: Tube
  • Input Type: -
  • Features: Power Good, Status Flag
  • Output Type: -
  • detail: Power Switch/Driver 1:2 1.3A 32-HTSSOP
