دیتاشیت MCP8024T-H/MP

MCP8024 Datasheet

مشخصات دیتاشیت

نام دیتاشیت MCP8024 Datasheet
حجم فایل 1357.355 کیلوبایت
نوع فایل pdf
تعداد صفحات 48

دانلود دیتاشیت MCP8024 Datasheet

MCP8024 Datasheet Datasheet

مشخصات

  • RoHS: true
  • Type: 无刷直流BLDC
  • Category: Power Supply Chip/Motor Driver ICs
  • Datasheet: Microchip Tech MCP8024T-H/MP
  • Interface: PWM
  • Output Current: -
  • Supply Voltage: 6V~28V
  • Operating Temperature: -40°C~+150°C@(Ta)
  • Package: QFN-40-EP(5x5)
  • Manufacturer: Microchip Tech
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Motor Type - Stepper: -
  • Motor Type - AC, DC: Brushless DC (BLDC)
  • Function: Controller - Commutation, Direction Management
  • Output Configuration: Pre-Driver - Half Bridge (3)
  • Technology: Power MOSFET
  • Step Resolution: -
  • Applications: General Purpose
  • Current - Output: -
  • Voltage - Supply: 6V ~ 28V
  • Voltage - Load: -
  • Mounting Type: Surface Mount
  • Package / Case: 40-VFQFN Exposed Pad
  • Supplier Device Package: 40-QFN (5x5)
  • Base Part Number: MCP8024
  • detail: Motor Driver Power MOSFET PWM 40-QFN (5x5)
