TPS77618QPWPREP دیتاشیت

TPS77618QPWPREP

مشخصات دیتاشیت

نام دیتاشیت TPS77618QPWPREP
حجم فایل 105.257 کیلوبایت
نوع فایل pdf
تعداد صفحات 25

مشاهده دیتاشیت TPS77618QPWPREP

دانلود دیتاشیت

سایر مستندات

TPS77601/15/18/25/28/33-EP 25 pages

مشخصات فنی

  • RoHS: true
  • Category: Power Supply Chip/Linear Voltage Regulators (LDO)
  • Datasheet: Texas Instruments TPS77618QPWPREP
  • Output Current: 500mA
  • Output Voltage: 1.8V
  • Output Polarity: positive
  • Number of Outputs: 1
  • Maximum Input Voltage: 10V
  • Operating Temperature: -40°C~+125°C
  • Quiescent Current (Ground Current): 125uA
  • Power Supply Rejection Ratio (PSRR): 60dB@(100Hz)
  • Package: TSSOP-20-EP
  • Manufacturer: Texas Instruments
  • Series: -
  • Voltage Dropout (Max): -
  • Package / Case: 20-PowerTSSOP (0.173", 4.40mm Width)
  • Base Part Number: TPS776
  • Supplier Device Package: 20-HTSSOP
  • Current - Output: 500mA
  • Current - Quiescent (Iq): 125µA
  • Part Status: Active
  • Voltage - Input (Max): 10V
  • Mounting Type: Surface Mount
  • Control Features: Enable, Power Good
  • Protection Features: Over Current, Over Temperature, Reverse Polarity
  • Voltage - Output (Min/Fixed): 1.8V
  • PSRR: 60dB (100Hz)
  • Voltage - Output (Max): -
  • Packaging: Cut Tape (CT)
  • Output Configuration: Positive
  • Number of Regulators: 1
  • Output Type: Fixed
  • detail: Linear Voltage Regulator IC 1 Output 500mA 20-HTSSOP
