TC913(A, B) Datasheet

TC913(A, B)

Datasheet specifications

Datasheet's name TC913(A, B)
File size 194.42 KB
File type pdf
Number of pages 14

Download Datasheet TC913(A, B)

Download Datasheet

Other documentations

TC913BCPA 14 pages

Technical specifications

  • RoHS: true
  • Category: Operational Amplifier/Comparator/Precision OpAmps
  • Datasheet: Microchip Tech TC913ACPA
  • Number of Circuits: 2
  • -3db Bandwidth(G=1): -
  • Operating Temperature: 0°C~+70°C
  • Current - Input Bias(Ib): 90pA
  • Gain Bandwidth Product(GBP): 1.5MHz
  • Voltage - Input Offset(Vos): 5uV
  • Package: PDIP-8
  • Manufacturer: Microchip Tech
  • Series: -
  • Packaging: Tube
  • Part Status: Active
  • Amplifier Type: Zero-Drift
  • Output Type: -
  • Slew Rate: 2.5V/µs
  • Gain Bandwidth Product: 1.5MHz
  • Current - Input Bias: 90pA
  • Voltage - Input Offset: 5µV
  • Current - Supply: 650µA
  • Voltage - Supply, Single/Dual (±): 7V ~ 16V, ±3.5V ~ 8.3V
  • Mounting Type: Through Hole
  • Package / Case: 8-DIP (0.300", 7.62mm)
  • Supplier Device Package: 8-PDIP
  • Base Part Number: TC913A
  • detail: Zero-Drift Amplifier 2 Circuit 8-PDIP
