دیتاشیت ATSAM3A8CA-CU
مشخصات دیتاشیت
| نام دیتاشیت |
SAM3X/A Series
|
| حجم فایل |
6108.708
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
1459
|
مشخصات
-
RoHS:
true
-
CPU Core:
ARM Cortex-M3
-
Category:
Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
-
Watchdog:
Yes
-
ADC (Bit):
12bit
-
DAC (Bit):
12bit
-
Datasheet:
Microchip Tech ATSAM3A8CA-CU
-
CPU Maximum Speed:
84MHz
-
GPIO Ports Number:
63
-
Low-Voltage Detect:
Yes
-
Internal Oscillator:
Yes
-
Direct Memory Access:
Yes
-
Program Storage Size:
512KB
-
Universal Serial Bus:
Yes
-
Operating Voltage Range:
1.62V~3.6V
-
Infrared Data Association:
Yes
-
Operating Temperature Range:
-40°C~+85°C
-
Package:
TFBGA-100
-
Manufacturer:
Microchip Tech
-
Series:
SAM3A
-
Packaging:
Tray
-
Part Status:
Active
-
Core Processor:
ARM® Cortex®-M3
-
Core Size:
32-Bit
-
Speed:
84MHz
-
Connectivity:
CANbus, I²C, IrDA, LINbus, MMC, SPI, SSC, UART/USART, USB
-
Peripherals:
Brown-out Detect/Reset, DMA, I²S, POR, PWM, WDT
-
Number of I/O:
63
-
Program Memory Size:
512KB (512K x 8)
-
Program Memory Type:
FLASH
-
EEPROM Size:
-
-
RAM Size:
96K x 8
-
Voltage - Supply (Vcc/Vdd):
1.62V ~ 3.6V
-
Data Converters:
A/D 16x12b; D/A 2x12b
-
Oscillator Type:
Internal
-
Operating Temperature:
-40°C ~ 85°C (TA)
-
Mounting Type:
Surface Mount
-
Package / Case:
100-TFBGA
-
Supplier Device Package:
100-TFBGA (9x9)
-
Base Part Number:
ATSAM3A
-
detail:
ARM® Cortex®-M3 SAM3A Microcontroller IC 32-Bit 84MHz 512KB (512K x 8) FLASH 100-TFBGA (9x9)
