TPS5100IPW دیتاشیت

TPS5100IPW

مشخصات دیتاشیت

نام دیتاشیت TPS5100IPW
حجم فایل 81.707 کیلوبایت
نوع فایل pdf
تعداد صفحات 15

مشاهده دیتاشیت TPS5100IPW

دانلود دیتاشیت

سایر مستندات

TPS5100 14 pages

مشخصات فنی

  • RoHS: true
  • Category: Power Supply Chip/DC-DC Controllers
  • Function: boost converterType;Buck-boost type
  • Topology: Boost;Step-down-Boost
  • Datasheet: Texas Instruments TPS5100IPW
  • Input Voltage: 2.5V~7V
  • Duty Cycle (Max): 100%
  • Number of Outputs: 3
  • Switching Frequency: 1MHz
  • Operating Temperature: -40°C~+85°C@(TA)
  • Synchronous Rectification: NO
  • Package: TSSOP-16
  • Manufacturer: Texas Instruments
  • Voltage - Supply (Vcc/Vdd): 2.5V ~ 7V
  • Base Part Number: TPS510
  • Package / Case: 16-TSSOP (0.173", 4.40mm Width)
  • Output Configuration: Positive
  • Series: -
  • Supplier Device Package: 16-TSSOP
  • Frequency - Switching: 50kHz ~ 1MHz
  • Part Status: Active
  • Mounting Type: Surface Mount
  • Control Features: Dead Time Control, Enable, Frequency Control
  • Clock Sync: No
  • Serial Interfaces: -
  • Packaging: Tube
  • Synchronous Rectifier: No
  • Output Type: Transistor Driver
  • Output Phases: 1
  • detail: Boost, Buck-Boost Regulator Positive Output Step-Up, Step-Up/Step-Down DC-DC Controller IC 16-TSSOP
