دیتاشیت SN74ALS642A-1NSR

مشخصات دیتاشیت

دانلود دیتاشیت SN74ALS641A-42A, SN74AS641	SN74ALS641A-42A, SN74AS641 Datasheet

RoHS: true
Category: Logic ICs/Buffer/Driver/Transceiver
Datasheet: Texas Instruments SN74ALS642A-1NSR
Input type: -
output type: Open Collector
Sink Current: 24mA
Source Current: -
Supply Voltage: 4.5V~5.5V
Operating Temperature: 0°C~+70°C
Package: SOP-20-208mil
Manufacturer: Texas Instruments
Series: 74ALS
Package / Case: 20-SOIC (0.209", 5.30mm Width)
Number of Bits per Element: 8
Number of Elements: 1
Supplier Device Package: 20-SO
Part Status: Active
Current - Output High, Low: -, 24mA
Mounting Type: Surface Mount
Base Part Number: SN74ALS6
Voltage - Supply: 4.5V ~ 5.5V
Packaging: Tape & Reel (TR)
Logic Type: Transceiver, Inverting
detail: Transceiver, Inverting 1 Element 8 Bit per Element Open Collector Output 20-SO
