TPS53624RHAT دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت TPS53624RHAT	دانلود دیتاشیت

TPS53624 48 pages

RoHS: true
Category: Power Supply Chip/DC-DC Controllers
Function: Step-down type
Topology: Step-down
Datasheet: Texas Instruments TPS53624RHAT
Input Voltage: 3V~28V
Duty Cycle (Max): -
Number of Outputs: 2
Switching Frequency: 200kHz;300kHz;400kHz;500kHz
Operating Temperature: -10°C~+105°C@(TA)
Synchronous Rectification: Yes
Package: QFN-40-EP(6x6)
Manufacturer: Texas Instruments
Voltage - Supply (Vcc/Vdd): 3V ~ 28V
Base Part Number: TPS536
Package / Case: 40-VFQFN Exposed Pad
Output Configuration: Positive
Series: D-CAP+™, Eco-Mode™
Supplier Device Package: 40-VQFN (6x6)
Frequency - Switching: 200kHz, 300kHz, 400kHz, 500kHz
Part Status: Active
Mounting Type: Surface Mount
Control Features: Current Limit, Enable, On Time Control, Phase Control, Power Good, Slew Control
Clock Sync: No
Serial Interfaces: -
Packaging: Cut Tape (CT)
Synchronous Rectifier: Yes
Output Type: Transistor Driver
Output Phases: 2
detail: Buck Regulator Positive Output Step-Down DC-DC Controller IC 40-VQFN (6x6)
