UCC1807, 2807, 3807 -1/- 2/-3 数据手册
数据手册规格
| 数据手册名称 | UCC1807, 2807, 3807 -1/- 2/-3 |
|---|---|
| 文件大小 | 3362.446 千字节 |
| 文件类型 | |
| 页数 | 15 |
下载数据手册 UCC1807, 2807, 3807 -1/- 2/-3 |
下载数据手册 |
|---|
其他文档
UCC2807D-3 15 pages
技术规格
- RoHS: true
- Category: Power Supply Chip/DC-DC Controllers
- Function: boost converterType;Step-down type;Buck-boost type
- Topology: Step-down;Boost;Flyback;SEPIC
- Datasheet: Texas Instruments UCC3807D-3G4
- Input Voltage: 4.1V~13.5V
- Duty Cycle (Max): 78%
- Number of Outputs: 1
- Switching Frequency: 202kHz
- Operating Temperature: 0°C~+70°C@(TA)
- Synchronous Rectification: NO
- Package: SOIC-8
- Manufacturer: Texas Instruments
- Voltage - Supply (Vcc/Vdd): 4.1V ~ 13.5V
- Base Part Number: UCC380
- Package / Case: 8-SOIC (0.154", 3.90mm Width)
- Output Configuration: Positive
- Series: -
- Supplier Device Package: 8-SOIC
- Frequency - Switching: 202kHz
- Part Status: Active
- Mounting Type: Surface Mount
- Control Features: -
- Clock Sync: No
- Serial Interfaces: -
- Packaging: Tube
- Synchronous Rectifier: No
- Output Type: Transistor Driver
- Output Phases: 1
- detail: Buck, Boost, Flyback, Forward Converter, SEPIC Regulator Positive Output Step-Up, Step-Down, Step-Up/Step-Down DC-DC Controller IC 8-SOIC
