دیتاشیت TLC2652C-8DR

TLC2652, TLC2652A, TLC2652Y

مشخصات دیتاشیت

نام دیتاشیت TLC2652, TLC2652A, TLC2652Y
حجم فایل 1223.609 کیلوبایت
نوع فایل pdf
تعداد صفحات 41

دانلود دیتاشیت TLC2652, TLC2652A, TLC2652Y

TLC2652, TLC2652A, TLC2652Y Datasheet

مشخصات

  • RoHS: true
  • Category: Operational Amplifier/Comparator/Precision OpAmps
  • Datasheet: Texas Instruments TLC2652C-8DR
  • Rail to Rail: Single-Ended
  • Number of Circuits: 1
  • -3db Bandwidth(G=1): -
  • Operating Temperature: 0°C~+70°C
  • Current - Input Bias(Ib): 4pA
  • Gain Bandwidth Product(GBP): 1.9MHz
  • Voltage - Input Offset(Vos): 0.6uV
  • Package: SOP-8
  • Manufacturer: Texas Instruments
  • Series: LinCMOS™
  • Package / Case: 8-SOIC (0.154", 3.90mm Width)
  • Current - Supply: 1.5mA
  • Voltage - Input Offset: 0.6µV
  • Mounting Type: Surface Mount
  • Part Status: Active
  • Slew Rate: 3.1V/µs
  • Voltage - Supply, Single/Dual (±): 3.8V ~ 16V, ±1.9V ~ 8V
  • Gain Bandwidth Product: 1.9MHz
  • Amplifier Type: Zero-Drift
  • Current - Output / Channel: 50mA
  • Packaging: Tape & Reel (TR)
  • Base Part Number: TLC265
  • Current - Input Bias: 4pA
  • Output Type: -
  • Supplier Device Package: 8-SOIC
  • detail: Zero-Drift Amplifier 1 Circuit 8-SOIC
