UCC28950TPWRQ1 دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
UCC28950TPWRQ1
|
|
حجم فایل
|
82.465
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
49
|
مشخصات فنی
-
RoHS:
true
-
Category:
Power Supply Chip/DC-DC Controllers
-
Function:
Buck-boost type
-
Topology:
Full-Bridge
-
Datasheet:
Texas Instruments UCC28950TPWRQ1
-
Input Voltage:
8V~17V
-
Duty Cycle (Max):
95%
-
Number of Outputs:
6
-
Switching Frequency:
1MHz
-
Operating Temperature:
-40°C~+105°C@(TA)
-
Synchronous Rectification:
Yes
-
Package:
TSSOP-24
-
Manufacturer:
Texas Instruments
-
Voltage - Supply (Vcc/Vdd):
8V ~ 17V
-
Base Part Number:
UCC289
-
Package / Case:
24-TSSOP (0.173", 4.40mm Width)
-
Output Configuration:
Positive
-
Series:
Automotive, AEC-Q100
-
Supplier Device Package:
24-TSSOP
-
Frequency - Switching:
50kHz ~ 1MHz
-
Part Status:
Active
-
Mounting Type:
Surface Mount
-
Control Features:
Dead Time Control, Enable, Frequency Control, Soft Start
-
Clock Sync:
Yes
-
Serial Interfaces:
-
-
Packaging:
Tape & Reel (TR)
-
Synchronous Rectifier:
Yes
-
Output Type:
Transistor Driver
-
Output Phases:
1
-
detail:
Full-Bridge Regulator Positive Output Step-Up/Step-Down DC-DC Controller IC 24-TSSOP
