دیتاشیت HMC344ATCPZ-EP-PT
مشخصات دیتاشیت
| نام دیتاشیت | HMC344ATCPZ-EP |
|---|---|
| حجم فایل | 207.171 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 8 |
دانلود دیتاشیت HMC344ATCPZ-EP |
HMC344ATCPZ-EP Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Radio Frequency Chip/Antenna/RF Switches
- Datasheet: Analog Devices HMC344ATCPZ-EP-PT
- isolation: 32dB
- Insertion loss: 2.1dB
- Supply voltage: -5V~-3V
- Frequency range: 100MHz~8GHz
- operating temperature: -55°C~+125°C
- Package: LFCSP-16
- Manufacturer: Analog Devices
- Series: -
- Packaging: Strip
- Part Status: Active
- RF Type: General Purpose
- Topology: -
- Circuit: SP4T
- Test Frequency: 8GHz
- P1dB: 25dBm
- IIP3: 44dBm
- Features: -
- Impedance: 50Ohm
- Voltage - Supply: -3V ~ -5V
- Package / Case: 16-VFQFN Exposed Pad
- Supplier Device Package: 16-LFCSP (3x3)
- detail: RF Switch IC General Purpose SP4T 50Ohm 16-LFCSP (3x3)
