ADUM4137WBRNZ دیتاشیت

ADUM4137WBRNZ

مشخصات دیتاشیت

نام دیتاشیت ADUM4137WBRNZ
حجم فایل 98.656 کیلوبایت
نوع فایل pdf
تعداد صفحات 28

دانلود دیتاشیت ADUM4137WBRNZ

دانلود دیتاشیت

سایر مستندات

ADUM4137 28 pages

مشخصات فنی

  • RoHS: true
  • Category: Power Supply Chip/Gate Drive ICs
  • Datasheet: Analog Devices ADUM4137WBRNZ
  • Package: SOP-28-300mil
  • Manufacturer: Analog Devices
  • Series: Automotive, AEC-Q100
  • Packaging: Tube
  • Part Status: Active
  • Technology: Magnetic Coupling
  • Number of Channels: 1
  • Voltage - Isolation: 5000Vrms
  • Common Mode Transient Immunity (Min): 150kV/µs
  • Propagation Delay tpLH / tpHL (Max): 131ns, 137ns
  • Pulse Width Distortion (Max): 70ns (Min)
  • Rise / Fall Time (Typ): 105ns, 107ns
  • Current - Output High, Low: -
  • Current - Peak Output: 6A
  • Voltage - Forward (Vf) (Typ): -
  • Voltage - Output Supply: 12V ~ 25V
  • Operating Temperature: -40°C ~ 150°C
  • Mounting Type: Surface Mount
  • Package / Case: 28-BSSOP (0.295", 7.50mm Width)
  • Supplier Device Package: 28-SOIC_W_FP
  • Approval Agency: CSA, UR, VDE
  • detail: 6A Gate Driver Magnetic Coupling 5000Vrms 1 Channel 28-SOIC_W_FP
