INA2126E/250G4 数据手册
其他文档
INA126, INA2126 34 pages
技术规格
- RoHS: true
- Category: Operational Amplifier/Comparator/Instrumentation OpAmps
- Datasheet: Texas Instruments INA2126E/250G4
- Package: SSOP-16-150mil-0.635mm
- Manufacturer: Texas Instruments
- Series: -
- Package / Case: 16-SSOP (0.154", 3.90mm Width)
- Number of Circuits: 2
- Current - Supply: 175µA
- Voltage - Input Offset: 100µV
- Mounting Type: Surface Mount
- Part Status: Active
- Slew Rate: 0.4V/µs
- Voltage - Supply, Single/Dual (±): 2.7V ~ 36V, ±1.35V ~ 18V
- Operating Temperature: -40°C ~ 85°C
- Amplifier Type: Instrumentation
- Current - Output / Channel: 10mA
- -3db Bandwidth: 200kHz
- Packaging: Tape & Reel (TR)
- Base Part Number: INA2126
- Current - Input Bias: 10nA
- Output Type: -
- Supplier Device Package: 16-SSOP
- detail: Instrumentation Amplifier 2 Circuit 16-SSOP
