ADUM6420ABRNZ5 دیتاشیت

ADUM6420ABRNZ5

مشخصات دیتاشیت

نام دیتاشیت ADUM6420ABRNZ5
حجم فایل 100.945 کیلوبایت
نوع فایل pdf
تعداد صفحات 29

دانلود دیتاشیت ADUM6420ABRNZ5

دانلود دیتاشیت

سایر مستندات

ADuM6420A-22A 29 pages

مشخصات فنی

  • RoHS: true
  • Category: Communication Interface Chip/UART/485/232/Digital Isolators
  • Datasheet: Analog Devices ADUM6420ABRNZ5
  • Applications: -
  • Isolation Technology: -
  • Voltage Isolation or Not: -
  • Package: SOIC-28-300mil
  • Manufacturer: Analog Devices
  • Series: IsoPower®, iCoupler®
  • Part Status: Active
  • Technology: Magnetic Coupling
  • Type: RS232
  • Isolated Power: No
  • Number of Channels: 4
  • Inputs - Side 1/Side 2: 4/0
  • Channel Type: Unidirectional
  • Voltage - Isolation: 5000Vrms
  • Common Mode Transient Immunity (Min): 75kV/µs
  • Data Rate: 100Mbps
  • Propagation Delay tpLH / tpHL (Max): 17ns, 17ns
  • Pulse Width Distortion (Max): 5ns
  • Rise / Fall Time (Typ): 2.5ns, 2.5ns
  • Voltage - Supply: 1.7V ~ 5.5V
  • Operating Temperature: -40°C ~ 125°C
  • Mounting Type: Surface Mount
  • Package / Case: 28-BSSOP (0.295", 7.50mm Width)
  • Supplier Device Package: 28-SOIC-W-FP
  • detail: RS232 Digital Isolator 5000Vrms 4 Channel 100Mbps 75kV/µs CMTI 28-BSSOP (0.295", 7.50mm Width)
