ADG528FBPZ دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت ADG528FBPZ	دانلود دیتاشیت

ADG528F 16 pages

RoHS: true
Category: Communication Interface Chip/UART/485/232/Analog Switches / Multiplexers
Datasheet: Analog Devices ADG528FBPZ
Turn-on time: 250ns
Turn-off time: 250ns
Supply Voltage: 15V
Number of Channels: 1
On-State Resistance (Max): 300Ω
Package: PLCC-20
Manufacturer: Analog Devices
Series: -
Packaging: Tube
Part Status: Obsolete
Switch Circuit: -
Multiplexer/Demultiplexer Circuit: 8:1
Number of Circuits: 1
Channel-to-Channel Matching (ΔRon): 15Ohm
Voltage - Supply, Single (V+): 15V
Voltage - Supply, Dual (V±): ±15V
Switch Time (Ton, Toff) (Max): 250ns, 250ns
-3db Bandwidth: -
Charge Injection: 4pC
Channel Capacitance (CS(off), CD(off)): 5pF, 50pF
Current - Leakage (IS(off)) (Max): 1nA
Crosstalk: -
Operating Temperature: -40°C ~ 85°C (TA)
Mounting Type: Surface Mount
Package / Case: 20-LCC (J-Lead)
Supplier Device Package: 20-PLCC (9x9)
Base Part Number: ADG528
detail: 1 Circuit IC Switch 8:1 300Ohm (Typ) 20-PLCC (9x9)
