ADV7120 دیتاشیت

ADV7120

مشخصات دیتاشیت

نام دیتاشیت ADV7120
حجم فایل 193.251 کیلوبایت
نوع فایل pdf
تعداد صفحات 12

دانلود دیتاشیت ADV7120

دانلود دیتاشیت

سایر مستندات

ADV7120KSTZ50 12 pages

مشخصات فنی

  • RoHS: true
  • Category: ADC/DAC/Data Conversion/Digital To Analog Converters (DACs)
  • Datasheet: Analog Devices ADV7120KSTZ30
  • Interface: Parallel
  • Resolution: 8Bit
  • Output Type: Current-非缓冲
  • Supply Voltage: 5V
  • Integral nonlinearity: ±1LSB;±0.5LSB
  • Operating Temperature: 0°C~+70°C
  • Package: LQFP-48(7x7)
  • Manufacturer: Analog Devices
  • Series: -
  • Packaging: Tray
  • Part Status: Active
  • Number of Bits: 8
  • Number of D/A Converters: 3
  • Settling Time: -
  • Differential Output: No
  • Data Interface: Parallel
  • Reference Type: External
  • Voltage - Supply, Analog: 5V
  • Voltage - Supply, Digital: 5V
  • INL/DNL (LSB): ±1 (Max), ±0.5 (Max)
  • Architecture: Current Source
  • Package / Case: 48-LQFP
  • Supplier Device Package: 48-LQFP (7x7)
  • Mounting Type: Surface Mount
  • Base Part Number: ADV7120
  • detail: 8 Bit Digital to Analog Converter 3 48-LQFP (7x7)
