- دیتاشیت AD5141BCPZ100-RL7
AD5141BCPZ100-RL7 دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | AD5141BCPZ100-RL7 |
|---|---|
| حجم فایل | 96.975 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 32 |
دانلود دیتاشیت AD5141BCPZ100-RL7 |
دانلود دیتاشیت |
|---|
سایر مستندات
AD5121,41 32 pages
مشخصات فنی
- RoHS: true
- Category: ADC/DAC/Data Conversion/Digital Potentiometers
- Datasheet: Analog Devices AD5141BCPZ100-RL7
- Precision: ±8%
- Interface Type: I2C;SPI
- Number of Taps: 256
- Supply Voltage: 2.3V~5.5V;2.25V~2.75V
- Number of Channels: 1
- Operating Temperature: -40°C~+125°C
- Resistance Value (Ohms): 100kΩ
- Temperature Coefficient (Typ): 35ppm/°C
- Package: LFCSP-16-EP(3x3)
- Manufacturer: Analog Devices
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- Taper: Linear
- Configuration: Potentiometer
- Number of Circuits: 1
- Resistance (Ohms): 100k
- Interface: I²C, SPI
- Memory Type: Non-Volatile
- Voltage - Supply: 2.3V ~ 5.5V, ±2.25V ~ 2.75V
- Features: Selectable Address
- Tolerance: ±8%
- Mounting Type: Surface Mount
- Supplier Device Package: 16-LFCSP-WQ (3x3)
- Package / Case: 16-WFQFN Exposed Pad, CSP
- Resistance - Wiper (Ohms) (Typ): 130
- Base Part Number: AD5141
- detail: Digital Potentiometer 100k Ohm 1 Circuit 256 Taps I²C, SPI Interface 16-LFCSP-WQ (3x3)
