CC2570RHAT دیتاشیت

CC2570RHAT

مشخصات دیتاشیت

نام دیتاشیت CC2570RHAT
حجم فایل 79.556 کیلوبایت
نوع فایل pdf
تعداد صفحات 34

مشاهده دیتاشیت CC2570RHAT

دانلود دیتاشیت

سایر مستندات

Analog Signal Chain Guide 11 pages

CC2570,CC2571 31 pages

مشخصات فنی

  • RoHS: true
  • Category: Radio Frequency Chip/Antenna/RF Transceiver ICs
  • Data Rate: 1Mbps
  • Datasheet: Texas Instruments CC2570RHAT
  • Interface: SPI,UART
  • Applications: General-purpose ISM>1GHz
  • Frequency Range: 2.4GHz
  • Receive Current: 23.7mA
  • Operating Voltage: 2V~3.6V
  • Operating Temperature: -40°C~+85°C
  • Current Of Transmitting: 25.9mA
  • Package: QFN-40-EP(6x6)
  • Manufacturer: Texas Instruments
  • Type: TxRx Only
  • Sensitivity: -86dBm
  • Base Part Number: CC2570
  • Current - Transmitting: 25.9mA ~ 34.3mA
  • Frequency: 2.4GHz
  • Package / Case: 40-VFQFN Exposed Pad
  • Memory Size: -
  • Modulation: GFSK
  • Voltage - Supply: 2V ~ 3.6V
  • Series: -
  • RF Family/Standard: General ISM > 1GHZ
  • Protocol: ANT™
  • Supplier Device Package: 40-VQFN (6x6)
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Mounting Type: Surface Mount
  • Serial Interfaces: SPI, UART
  • Power - Output: 4dBm
  • Data Rate (Max): 1Mbps
  • Current - Receiving: 23.7mA
  • detail: IC RF TxRx Only General ISM > 1GHZ ANT™ 2.4GHz 40-VFQFN Exposed Pad
