ADP322,323 دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
ADP322,323
|
|
حجم فایل
|
854.415
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
24
|
مشخصات فنی
-
Manufacturer:
Analog Devices Inc.
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Output Configuration:
Positive
-
Output Type:
Fixed
-
Number of Regulators:
3
-
Voltage - Input (Max):
5.5V
-
Voltage - Output (Min/Fixed):
1.2V, 2.5V, 3.3V
-
Voltage - Output (Max):
-
-
Voltage Dropout (Max):
-, 0.17V @ 200mA, 0.17V @ 200mA
-
Current - Output:
200mA, 200mA, 200mA
-
Current - Quiescent (Iq):
160µA
-
Current - Supply (Max):
380µA
-
PSRR:
-
-
Control Features:
Enable
-
Protection Features:
Over Current, Over Temperature, Under Voltage Lockout (UVLO)
-
Operating Temperature:
-40°C ~ 125°C
-
Mounting Type:
Surface Mount
-
Package / Case:
16-WFQFN Exposed Pad, CSP
-
Supplier Device Package:
16-LFCSP-WQ (3x3)
-
Base Part Number:
ADP322
-
detail:
Linear Voltage Regulator IC 3 Output 200mA, 200mA, 200mA 16-LFCSP-WQ (3x3)
