ADRF6655ACPZ-R7 Datasheet
Datasheet specifications
| Datasheet's name | ADRF6655ACPZ-R7 |
|---|---|
| File size | 1319.878 KB |
| File type | |
| Number of pages | 44 |
Download Datasheet ADRF6655ACPZ-R7 |
Download Datasheet |
|---|
Other documentations
ADRF6655 41 pages
Technical specifications
- Manufacturer: Analog Devices Inc.
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Discontinued at Digi-Key
- RF Type: General Purpose
- Frequency: 100MHz ~ 2.5GHz
- Number of Mixers: 1
- Gain: 6dB
- Noise Figure: 12dB
- Secondary Attributes: Up/Down Converter
- Current - Supply: 310mA
- Voltage - Supply: 4.75V ~ 5.25V
- Mounting Type: Surface Mount
- Package / Case: 40-VFQFN Exposed Pad, CSP
- Supplier Device Package: 40-LFCSP-VQ (6x6)
- Base Part Number: ADRF6655
- detail: RF Mixer IC General Purpose Up/Down Converter 100MHz ~ 2.5GHz 40-LFCSP-VQ (6x6)
