دیتاشیت ADP1614ACPZ-R7
مشخصات دیتاشیت
| نام دیتاشیت |
ADP1614
|
| حجم فایل |
512.026
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
18
|
مشخصات
-
Manufacturer:
Analog Devices Inc.
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Function:
Step-Up
-
Output Configuration:
Positive
-
Topology:
Boost
-
Output Type:
Adjustable
-
Number of Outputs:
1
-
Voltage - Input (Min):
2.5V
-
Voltage - Input (Max):
5.5V
-
Voltage - Output (Min/Fixed):
2.5V
-
Voltage - Output (Max):
20V
-
Current - Output:
3A (Switch)
-
Frequency - Switching:
650kHz, 1.3MHz
-
Synchronous Rectifier:
No
-
Operating Temperature:
-40°C ~ 125°C (TJ)
-
Mounting Type:
Surface Mount
-
Package / Case:
10-VFDFN Exposed Pad, CSP
-
Supplier Device Package:
10-LFCSP-WD (3x3)
-
Base Part Number:
ADP1614
-
detail:
Boost Switching Regulator IC Positive Adjustable 2.5V 1 Output 3A (Switch) 10-VFDFN Exposed Pad, CSP
