دیتاشیت ADUM3070ARQZ-RL7
مشخصات دیتاشیت
| نام دیتاشیت | ADuM3070 Datasheet |
|---|---|
| حجم فایل | 775.072 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 20 |
دانلود دیتاشیت ADuM3070 Datasheet |
ADuM3070 Datasheet Datasheet |
|---|
مشخصات
- Manufacturer: Analog Devices Inc.
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- Function: Step-Up/Step-Down
- Output Configuration: Positive, Isolation Capable
- Topology: Push-Pull
- Output Type: Adjustable
- Number of Outputs: 1
- Voltage - Input (Min): 3V
- Voltage - Input (Max): 7V
- Voltage - Output (Min/Fixed): 3.3V
- Voltage - Output (Max): 24V
- Current - Output: 350mA
- Frequency - Switching: 200kHz ~ 1MHz
- Synchronous Rectifier: No
- Operating Temperature: -40°C ~ 105°C (TA)
- Mounting Type: Surface Mount
- Package / Case: 16-SSOP (0.154", 3.90mm Width)
- Supplier Device Package: 16-QSOP
- Base Part Number: ADUM3070
- detail: Push-Pull Switching Regulator IC Positive, Isolation Capable Adjustable 3.3V 1 Output 350mA 16-SSOP (0.154", 3.90mm Width)
