دیتاشیت ADP7118AUJZ-R7

ADP7118

مشخصات دیتاشیت

نام دیتاشیت ADP7118
حجم فایل 1530.759 کیلوبایت
نوع فایل pdf
تعداد صفحات 24

دانلود دیتاشیت ADP7118

ADP7118 Datasheet

مشخصات

  • RoHS: true
  • Category: Power Supply Chip/Linear Voltage Regulators (LDO)
  • Datasheet: Analog Devices ADP7118AUJZ-R7
  • Output Type: -
  • Package: SOT-23-5
  • Manufacturer: Analog Devices
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Output Configuration: Positive
  • Number of Regulators: 1
  • Voltage - Input (Max): 20V
  • Voltage - Output (Min/Fixed): 1.2V
  • Voltage - Output (Max): 19.58V
  • Voltage Dropout (Max): 0.42V @ 200mA
  • Current - Output: 200mA
  • Current - Quiescent (Iq): 140µA
  • Current - Supply (Max): 320µA
  • PSRR: 88dB ~ 50dB (10kHz ~ 1MHz)
  • Control Features: Enable, Soft Start
  • Protection Features: Over Current, Over Temperature
  • Operating Temperature: -40°C ~ 125°C (TA)
  • Mounting Type: Surface Mount
  • Package / Case: SOT-23-5 Thin, TSOT-23-5
  • Supplier Device Package: TSOT-23-5
  • Base Part Number: ADP7118
  • detail: Linear Voltage Regulator IC 1 Output 200mA TSOT-23-5
