دیتاشیت ADP7112ACBZ-1.2-R7
مشخصات دیتاشیت
| نام دیتاشیت | ADP7112 |
|---|---|
| حجم فایل | 591.193 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 21 |
دانلود دیتاشیت ADP7112 |
ADP7112 Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Power Supply Chip/Linear Voltage Regulators (LDO)
- Datasheet: Analog Devices ADP7112ACBZ-1.2-R7
- Output Current: 200mA
- Output Voltage: 1.2V~19V
- Output Polarity: positive
- Number of Outputs: 1
- Maximum Input Voltage: 20V
- Operating Temperature: -40°C~+125°C
- Quiescent Current (Ground Current): 140uA
- Package: WLCSP-6
- Manufacturer: Analog Devices
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- Output Configuration: Positive
- Output Type: Adjustable (Fixed)
- Number of Regulators: 1
- Voltage - Input (Max): 20V
- Voltage - Output (Min/Fixed): 1.2V
- Voltage - Output (Max): 19V
- Voltage Dropout (Max): -
- Current - Output: 200mA
- Current - Quiescent (Iq): 140µA
- Current - Supply (Max): 320µA
- PSRR: -
- Control Features: Enable, Soft Start
- Protection Features: Over Current, Over Temperature
- Mounting Type: Surface Mount
- Package / Case: 6-UFBGA, WLCSP
- Supplier Device Package: 6-WLCSP (0.95x1.16)
- Base Part Number: ADP7112
- detail: Linear Voltage Regulator IC 1 Output 200mA 6-WLCSP (0.95x1.16)
