ADG758,759 دیتاشیت

ADG758,759

مشخصات دیتاشیت

نام دیتاشیت ADG758,759
حجم فایل 361.753 کیلوبایت
نوع فایل pdf
تعداد صفحات 12

مشاهده دیتاشیت ADG758,759

دانلود دیتاشیت

سایر مستندات

ADG759BCPZ-REEL7 12 pages

مشخصات فنی

  • RoHS: true
  • Category: Logic ICs/Signal Switches / Encoders & Decoders / Multiplexers
  • Datasheet: Analog Devices ADG758BCPZ-REEL7
  • Package: LFCSP-20
  • Manufacturer: Analog Devices
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Switch Circuit: -
  • Multiplexer/Demultiplexer Circuit: 8:1
  • Number of Circuits: 1
  • On-State Resistance (Max): 4.5Ohm
  • Channel-to-Channel Matching (ΔRon): -
  • Voltage - Supply, Single (V+): 1.8V ~ 5.5V
  • Voltage - Supply, Dual (V±): ±2.5V
  • Switch Time (Ton, Toff) (Max): 14ns, 8ns (Typ)
  • -3db Bandwidth: 55MHz
  • Charge Injection: 3pC
  • Channel Capacitance (CS(off), CD(off)): 13pF, 85pF
  • Current - Leakage (IS(off)) (Max): 100pA
  • Crosstalk: -80dB @ 1MHz
  • Operating Temperature: -40°C ~ 85°C (TA)
  • Mounting Type: Surface Mount
  • Package / Case: 20-WFQFN Exposed Pad, CSP
  • Supplier Device Package: 20-LFCSP-WQ (4x4)
  • Base Part Number: ADG758
  • detail: 1 Circuit IC Switch 8:1 4.5Ohm 20-LFCSP-WQ (4x4)
