دیتاشیت ADG704BRMZ-REEL7
مشخصات دیتاشیت
| نام دیتاشیت |
ADG704
|
| حجم فایل |
113.46
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
8
|
مشخصات
-
RoHS:
true
-
Category:
Communication Interface Chip/UART/485/232/Analog Switches / Multiplexers
-
Datasheet:
Analog Devices ADG704BRMZ-REEL7
-
Turn-on time:
14ns
-
Turn-off time:
6ns
-
Supply Voltage:
1.8V~5.5V
-
Switch Circuit:
单刀四掷(SP4T)
-
Number of Channels:
1
-
On-State Resistance (Max):
4Ω
-
Package:
MSOP-10
-
Manufacturer:
Analog Devices
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Multiplexer/Demultiplexer Circuit:
4:1
-
Number of Circuits:
1
-
Channel-to-Channel Matching (ΔRon):
-
-
Voltage - Supply, Single (V+):
1.8V ~ 5V
-
Voltage - Supply, Dual (V±):
-
-
Switch Time (Ton, Toff) (Max):
14ns, 6ns (Typ)
-
-3db Bandwidth:
200MHz
-
Charge Injection:
3pC
-
Channel Capacitance (CS(off), CD(off)):
9pF, 37pF
-
Current - Leakage (IS(off)) (Max):
100pA
-
Crosstalk:
-82dB @ 1MHz
-
Operating Temperature:
-40°C ~ 85°C (TA)
-
Mounting Type:
Surface Mount
-
Package / Case:
10-TFSOP, 10-MSOP (0.118", 3.00mm Width)
-
Supplier Device Package:
10-µSOIC
-
Base Part Number:
ADG704
-
detail:
1 Circuit IC Switch 4:1 4Ohm 10-µSOIC
