دیتاشیت ADR421ARMZ-REEL7
مشخصات دیتاشیت
| نام دیتاشیت | ADR420,421,423,425 |
|---|---|
| حجم فایل | 463.412 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 24 |
دانلود دیتاشیت ADR420,421,423,425 |
ADR420,421,423,425 Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Power Supply Chip/Voltage References
- Datasheet: Analog Devices ADR421ARMZ-REEL7
- Tolerance: ±0.12%
- Output Type: Fixed
- Input Voltage: 4.5V~18V
- Output Current: 10mA
- Output Voltage: 2.5V
- Reference Type: series connection
- Supply Current: 600uA
- Operating Temperature: -40°C~+125°C@(Ta)
- Temperature Coefficient: 10ppm/°C
- Package: MSOP-8
- Manufacturer: Analog Devices
- Series: XFET®
- Packaging: Cut Tape (CT)
- Part Status: Active
- Voltage - Output (Min/Fixed): 2.5V
- Current - Output: 10mA
- Noise - 0.1Hz to 10Hz: 1.75µVp-p
- Noise - 10Hz to 10kHz: -
- Voltage - Input: 4.5V ~ 18V
- Current - Supply: 600µA
- Mounting Type: Surface Mount
- Package / Case: 8-TSSOP, 8-MSOP (0.118", 3.00mm Width)
- Supplier Device Package: 8-MSOP
- Base Part Number: ADR421
- detail: Series Voltage Reference IC ±0.12% 8-MSOP
