دیتاشیت ADR423ARZ-REEL7

ADR420,421,423,425

مشخصات دیتاشیت

نام دیتاشیت ADR420,421,423,425
حجم فایل 463.412 کیلوبایت
نوع فایل pdf
تعداد صفحات 24

دانلود دیتاشیت ADR420,421,423,425

ADR420,421,423,425 Datasheet

مشخصات

  • RoHS: true
  • Category: Power Supply Chip/Voltage References
  • Datasheet: Analog Devices ADR423ARZ-REEL7
  • Tolerance: ±0.13%
  • Output Type: Fixed
  • Input Voltage: 5V~18V
  • Output Current: 10mA
  • Output Voltage: 3V
  • Reference Type: series connection
  • Supply Current: 600uA
  • Noise - 10Hz to 10kHz: -
  • Operating Temperature: -40°C~+125°C@(Ta)
  • Noise - 1/10Hz to 10Hz: 2uVp-p
  • Temperature Coefficient: 10ppm/°C
  • Package: SOIC-8
  • Manufacturer: Analog Devices
  • Series: XFET®
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Voltage - Output (Min/Fixed): 3V
  • Current - Output: 10mA
  • Noise - 0.1Hz to 10Hz: 2µVp-p
  • Voltage - Input: 5V ~ 18V
  • Current - Supply: 600µA
  • Mounting Type: Surface Mount
  • Package / Case: 8-SOIC (0.154", 3.90mm Width)
  • Supplier Device Package: 8-SOIC
  • Base Part Number: ADR423
  • detail: Series Voltage Reference IC ±0.13% 8-SOIC
