ADP5014 دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت ADP5014	دانلود دیتاشیت

RoHS: true
Category: Power Supply Chip/DC-DC Converters
Function: Step-down type
Topology: Step-down
Datasheet: Analog Devices ADP5014ACPZ-R7
Output Type: Adjustable
Input Voltage: 2.75V~6V
Output Voltage: 0.5V~4.5V
Number of Outputs: 4
Switching Frequency: 2.5MHz
Output Current (Max): 2A;4A;1A
Operating Temperature: -40°C~+125°C
Synchronous Rectification: NO
Package: LFCSP-40
Manufacturer: Analog Devices
Series: -
Packaging: Cut Tape (CT)
Part Status: Active
Output Configuration: Positive
Voltage - Input (Min): 2.75V
Voltage - Input (Max): 6V
Voltage - Output (Min/Fixed): 0.5V
Voltage - Output (Max): 4.5V
Current - Output: 2A, 4A, 1A, 2A
Frequency - Switching: 500kHz ~ 2.5MHz
Synchronous Rectifier: No
Mounting Type: Surface Mount
Package / Case: 40-WFQFN Exposed Pad, CSP
Supplier Device Package: 40-LFCSP-WQ (6x6)
Base Part Number: ADP5014
detail: Buck Switching Regulator IC Positive Programmable 0.5V 4 Output 2A, 4A, 1A, 2A 40-WFQFN Exposed Pad, CSP
