دیتاشیت ADR431BRMZ-R7
مشخصات دیتاشیت
| نام دیتاشیت |
ADR430,1,3,4,5
|
| حجم فایل |
1091.629
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
23
|
مشخصات
-
RoHS:
true
-
Category:
Power Supply Chip/Voltage References
-
Datasheet:
Analog Devices ADR431BRMZ-R7
-
Tolerance:
±0.04%
-
Output Type:
Fixed
-
Input Voltage:
4.5V~18V
-
Output Current:
30mA
-
Output Voltage:
2.5V
-
Reference Type:
series connection
-
Supply Current:
800uA
-
Operating Temperature:
-40°C~+125°C@(Ta)
-
Temperature Coefficient:
3ppm/°C
-
Package:
MSOP-8
-
Manufacturer:
Analog Devices
-
Series:
XFET®
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Voltage - Output (Min/Fixed):
2.5V
-
Current - Output:
30mA
-
Noise - 0.1Hz to 10Hz:
3.5µVp-p
-
Noise - 10Hz to 10kHz:
-
-
Voltage - Input:
4.5V ~ 18V
-
Current - Supply:
800µA
-
Mounting Type:
Surface Mount
-
Package / Case:
8-TSSOP, 8-MSOP (0.118", 3.00mm Width)
-
Supplier Device Package:
8-MSOP
-
Base Part Number:
ADR431
-
detail:
Series Voltage Reference IC ±0.04% 8-MSOP
