دیتاشیت ADM3260ARSZ-RL7
مشخصات دیتاشیت
| نام دیتاشیت |
ADM3260
|
| حجم فایل |
460.045
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
19
|
مشخصات
-
RoHS:
true
-
Category:
Communication Interface Chip/UART/485/232/Digital Isolators
-
Datasheet:
Analog Devices ADM3260ARSZ-RL7
-
Applications:
I2C
-
Supply Voltage:
3V~5.5V
-
Forward Channel:
2
-
Reverse channel:
2
-
Number of Channels:
2
-
Isolation Technology:
Magnetic isolation
-
Operating Temperature:
-40°C~+105°C
-
Voltage Isolation or Not:
带电压隔离
-
Package:
SSOP-20-208mil
-
Manufacturer:
Analog Devices
-
Series:
IsoPower®, iCoupler®
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Technology:
Magnetic Coupling
-
Type:
I²C
-
Isolated Power:
Yes
-
Inputs - Side 1/Side 2:
2/2
-
Channel Type:
Bidirectional
-
Voltage - Isolation:
2500Vrms
-
Common Mode Transient Immunity (Min):
25kV/µs
-
Data Rate:
-
-
Propagation Delay tpLH / tpHL (Max):
-
-
Pulse Width Distortion (Max):
145ns, 85ns
-
Rise / Fall Time (Typ):
-
-
Voltage - Supply:
3V ~ 5.5V
-
Mounting Type:
Surface Mount
-
Package / Case:
20-SSOP (0.209", 5.30mm Width)
-
Supplier Device Package:
20-SSOP
-
Base Part Number:
ADM3260
-
detail:
I²C Digital Isolator 2500Vrms 2 Channel 25kV/µs CMTI 20-SSOP (0.209", 5.30mm Width)
