دیتاشیت AD8422BRMZ-R7

AD8422

مشخصات دیتاشیت

نام دیتاشیت AD8422
حجم فایل 654.952 کیلوبایت
نوع فایل pdf
تعداد صفحات 24

دانلود دیتاشیت AD8422

AD8422 Datasheet

مشخصات

  • RoHS: true
  • Category: Operational Amplifier/Comparator/Instrumentation OpAmps
  • Datasheet: Analog Devices AD8422BRMZ-R7
  • Rail to Rail: 轨到轨
  • -3db Bandwidth: 2.2MHz
  • Number of Circuits: 1
  • Operating Temperature: -40°C~+85°C
  • Current - Input Bias(Ib): 200pA
  • Gain Bandwidth Product(GBP): -
  • Voltage - Input Offset(Vos): 50uV
  • Package: MSOP-8
  • Manufacturer: Analog Devices
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Amplifier Type: Instrumentation
  • Output Type: Rail-to-Rail
  • Slew Rate: 0.8V/µs
  • Current - Input Bias: 200pA
  • Voltage - Input Offset: 50µV
  • Current - Supply: 300µA
  • Current - Output / Channel: 20mA
  • Voltage - Supply, Single/Dual (±): 3.6V ~ 36V, ±1.8V ~ 18V
  • Mounting Type: Surface Mount
  • Package / Case: 8-TSSOP, 8-MSOP (0.118", 3.00mm Width)
  • Supplier Device Package: 8-MSOP
  • Base Part Number: AD8422
  • detail: Instrumentation Amplifier 1 Circuit Rail-to-Rail 8-MSOP
