دیتاشیت AD5061YRJZ-1500RL7

AD5061 Series Datasheet

مشخصات دیتاشیت

نام دیتاشیت AD5061 Series Datasheet
حجم فایل 1738.441 کیلوبایت
نوع فایل pdf
تعداد صفحات 20

دانلود دیتاشیت AD5061 Series Datasheet

AD5061 Series Datasheet Datasheet

مشخصات

  • RoHS: true
  • Category: ADC/DAC/Data Conversion/Digital To Analog Converters (DACs)
  • Datasheet: Analog Devices AD5061YRJZ-1500RL7
  • Interface: SPI;DSP
  • Resolution: 16Bit
  • Output Type: Voltage-缓冲
  • Settling Time: 4us
  • Supply Voltage: 2.7V~5.5V
  • Integral nonlinearity: ±0.5LSB
  • Operating Temperature: -40°C~+125°C
  • Package: SOT-23-8
  • Manufacturer: Analog Devices
  • Series: nanoDAC®
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Number of Bits: 16
  • Number of D/A Converters: 1
  • Differential Output: No
  • Data Interface: SPI, DSP
  • Reference Type: External
  • Voltage - Supply, Analog: 2.7V ~ 5.5V
  • Voltage - Supply, Digital: 2.7V ~ 5.5V
  • INL/DNL (LSB): ±0.5, ±0.5
  • Architecture: R-2R
  • Package / Case: SOT-23-8
  • Supplier Device Package: SOT-23-8
  • Mounting Type: Surface Mount
  • Base Part Number: AD5061
  • detail: 16 Bit Digital to Analog Converter 1 SOT-23-8
