AD7380BCPZ-RL7 دیتاشیت

AD7380BCPZ-RL7

مشخصات دیتاشیت

نام دیتاشیت AD7380BCPZ-RL7
حجم فایل 104.026 کیلوبایت
نوع فایل pdf
تعداد صفحات 31

دانلود دیتاشیت AD7380BCPZ-RL7

دانلود دیتاشیت

سایر مستندات

AD7380-81 Datasheet 31 pages

مشخصات فنی

  • RoHS: true
  • Category: ADC/DAC/Data Conversion/Analog To Digital Converters (ADCs)
  • Datasheet: Analog Devices AD7380BCPZ-RL7
  • Interface: serial
  • resolution: 16Bit
  • Supply Voltage: 3V~3.6V
  • differential input: Yes
  • number of channels: 2
  • sampling frequency: 4MHz
  • Operating Temperature: -40°C~+125°C
  • Package: LFCSP-16
  • Manufacturer: Analog Devices
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Number of Bits: 16
  • Sampling Rate (Per Second): 4M
  • Number of Inputs: 2
  • Input Type: Differential
  • Data Interface: Serial
  • Configuration: S/H-ADC
  • Ratio - S/H:ADC: 0:2
  • Number of A/D Converters: 2
  • Architecture: SAR
  • Reference Type: External, Internal
  • Voltage - Supply, Analog: 3V ~ 3.6V
  • Voltage - Supply, Digital: 1.65V ~ 3.6V
  • Features: Simultaneous Sampling
  • Package / Case: 16-WFQFN Exposed Pad, CSP
  • Supplier Device Package: 16-LFCSP (3x3)
  • Mounting Type: Surface Mount
  • detail: 16 Bit Analog to Digital Converter 2 Input 2 SAR 16-LFCSP (3x3)
