دیتاشیت ADG1636BCPZ-REEL7

مشخصات دیتاشیت

دانلود دیتاشیت ADG1636	ADG1636 Datasheet

RoHS: true
Category: Communication Interface Chip/UART/485/232/Analog Switches / Multiplexers
Datasheet: Analog Devices ADG1636BCPZ-REEL7
Turn-on time: 95ns
Turn-off time: 161ns
Supply Voltage: 3.3V~16V
Switch Circuit: SPDT(SPDT)
Number of Channels: 2
On-State Resistance (Max): 1.1Ω
Package: LFCSP-16
Manufacturer: Analog Devices
Series: -
Packaging: Cut Tape (CT)
Part Status: Active
Multiplexer/Demultiplexer Circuit: 2:1
Number of Circuits: 2
Channel-to-Channel Matching (ΔRon): 30mOhm
Voltage - Supply, Single (V+): 3.3V ~ 16V
Voltage - Supply, Dual (V±): ±3.3V ~ 8V
Switch Time (Ton, Toff) (Max): 95ns, 161ns
-3db Bandwidth: 27MHz
Charge Injection: 150pC
Channel Capacitance (CS(off), CD(off)): 65pF, 120pF
Current - Leakage (IS(off)) (Max): 250pA
Crosstalk: -90dB @ 1MHz
Operating Temperature: -40°C ~ 125°C (TA)
Mounting Type: Surface Mount
Package / Case: 16-VQFN Exposed Pad, CSP
Supplier Device Package: 16-LFCSP-VQ (4x4)
Base Part Number: ADG1636
detail: 2 Circuit IC Switch 2:1 1.1Ohm 16-LFCSP-VQ (4x4)
