دیتاشیت MPC509AU/1KG4
مشخصات دیتاشیت
| نام دیتاشیت |
MPC508A,509A
|
| حجم فایل |
1623.503
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
21
|
مشخصات
-
Switch Circuit:
SP4T
-
Charge Injection:
-
-
Voltage - Supply, Dual (V±):
±5V ~ 22V
-
Crosstalk:
-
-
Base Part Number:
MPC509
-
Operating Temperature:
-40°C ~ 85°C (TA)
-
Switch Time (Ton, Toff) (Max):
200ns, 250ns (Typ)
-
Multiplexer/Demultiplexer Circuit:
4:1
-
Package / Case:
16-SOIC (0.295", 7.50mm Width)
-
Channel Capacitance (CS(off), CD(off)):
5pF, 12pF
-
Channel-to-Channel Matching (ΔRon):
-
-
Supplier Device Package:
16-SOIC
-
Series:
-
-
Current - Leakage (IS(off)) (Max):
500pA (Typ)
-
Number of Circuits:
2
-
Part Status:
Active
-
Mounting Type:
Surface Mount
-
Voltage - Supply, Single (V+):
-
-
Manufacturer:
Texas Instruments
-
-3db Bandwidth:
-
-
On-State Resistance (Max):
1.5kOhm
-
Packaging:
Tape & Reel (TR)
-
detail:
2 Circuit IC Switch 4:1 1.5kOhm 16-SOIC
