دیتاشیت ADM3251EARWZ-REEL

مشخصات دیتاشیت

دانلود دیتاشیت ADM3251E	ADM3251E Datasheet

RoHS: true
Types: transceiver
Category: Communication Interface Chip/UART/485/232/RS232 ICs
Data Rate: 460Kbps
Datasheet: Analog Devices ADM3251EARWZ-REEL
Supply Voltage: 4.5V~5.5V
Driver/receiver: 1/1
Package: SOP-20-300mil
Manufacturer: Analog Devices
Series: IsoPower®, iCoupler®
Packaging: Cut Tape (CT)
Part Status: Active
Technology: Magnetic Coupling
Type: RS232
Isolated Power: Yes
Number of Channels: 2
Inputs - Side 1/Side 2: 1/1
Channel Type: Unidirectional
Voltage - Isolation: 2500Vrms
Common Mode Transient Immunity (Min): 25kV/µs
Propagation Delay tpLH / tpHL (Max): 135ns, 190ns
Pulse Width Distortion (Max): -
Rise / Fall Time (Typ): 2.3ns, 2.3ns
Voltage - Supply: 4.5V ~ 5.5V
Operating Temperature: -40°C ~ 85°C
Mounting Type: Surface Mount
Package / Case: 20-SOIC (0.295", 7.50mm Width)
Supplier Device Package: 20-SOIC
Base Part Number: ADM3251
detail: RS232 Digital Isolator 2500Vrms 2 Channel 460Kbps 25kV/µs CMTI 20-SOIC (0.295", 7.50mm Width)
