دیتاشیت REF191ESZ-REEL

REF191ESZ-REEL

مشخصات دیتاشیت

نام دیتاشیت REF191ESZ-REEL
حجم فایل 91.84 کیلوبایت
نوع فایل pdf
تعداد صفحات 28

REF191ESZ-REEL

دانلود دیتاشیت

سایر مستندات

REF19x Series 28 pages

مشخصات فنی

  • RoHS: true
  • Category: Power Supply Chip/Voltage References
  • Datasheet: Analog Devices REF191ESZ-REEL
  • Tolerance: ±0.1%
  • Output Type: Fixed
  • Input Voltage: 3V~15V
  • Output Current: 30mA
  • Output Voltage: 2.048V
  • Reference Type: series connection
  • Supply Current: 45uA
  • Noise - 10Hz to 10kHz: -
  • Operating Temperature: -40°C~+85°C@(Ta)
  • Noise - 1/10Hz to 10Hz: 20uVp-p
  • Temperature Coefficient: 5ppm/°C
  • Package: SOIC-8
  • Manufacturer: Analog Devices
  • Series: REF19
  • Packaging: Tube
  • Part Status: Obsolete
  • Voltage - Output (Min/Fixed): 2.048V
  • Current - Output: 30mA
  • Noise - 0.1Hz to 10Hz: 20µVp-p
  • Voltage - Input: 3V ~ 15V
  • Current - Supply: 45µA
  • Mounting Type: Surface Mount
  • Package / Case: 8-SOIC (0.154", 3.90mm Width)
  • Supplier Device Package: 8-SOIC
  • Base Part Number: REF191
  • detail: Series Voltage Reference IC ±0.1% 8-SOIC
