دیتاشیت ADS7842EB/1K

ADS7842 Datasheet

مشخصات دیتاشیت

نام دیتاشیت ADS7842 Datasheet
حجم فایل 1015.991 کیلوبایت
نوع فایل pdf
تعداد صفحات 22

دانلود دیتاشیت ADS7842 Datasheet

ADS7842 Datasheet Datasheet

مشخصات

  • RoHS: true
  • Category: ADC/DAC/Data Conversion/Analog To Digital Converters (ADCs)
  • Datasheet: Texas Instruments ADS7842EB/1K
  • Interface: Parallel
  • resolution: 12Bit
  • Supply Voltage: 2.7V~3.6V;5V
  • number of channels: 4
  • sampling frequency: 200kHz
  • Operating Temperature: -40°C~+85°C
  • Package: SSOP-28-208mil
  • Manufacturer: Texas Instruments
  • Configuration: MUX-S/H-ADC
  • Voltage - Supply, Analog: 2.7V ~ 3.6V, 5V
  • Base Part Number: ADS7842
  • Voltage - Supply, Digital: 2.7V ~ 3.6V, 5V
  • Number of Bits: 12
  • Series: -
  • Package / Case: 28-SSOP (0.209", 5.30mm Width)
  • Packaging: Tube
  • Supplier Device Package: 28-SSOP
  • Number of Inputs: 4
  • Ratio - S/H:ADC: 1:1
  • Reference Type: External
  • Mounting Type: Surface Mount
  • Part Status: Active
  • Sampling Rate (Per Second): 200k
  • Number of A/D Converters: 1
  • Data Interface: Parallel
  • Architecture: SAR
  • Input Type: Single Ended
  • Features: Selectable Address
  • detail: 12 Bit Analog to Digital Converter 4 Input 1 SAR 28-SSOP
