ADM1178 Datasheet

ADM1178

Datasheet specifications

Datasheet's name ADM1178
File size 1042.55 KB
File type pdf
Number of pages 24

Download Datasheet ADM1178

Download Datasheet

Other documentations

ADM1178-1ARMZ-R7 24 pages

Technical specifications

  • RoHS: true
  • Install: Surface MountType
  • Category: TVS/Fuse/Board Level Protection/Surge Suppressors
  • Datasheet: Analog Devices ADM1178-2ARMZ-R7
  • Voltage Rating: 3.15V~16.5V
  • Number of Lines: 1
  • Operating temperature: -40°C~+85°C
  • Package: MSOP-10
  • Manufacturer: Analog Devices
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Type: Hot Swap Controller, Monitor
  • Number of Channels: 1
  • Internal Switch(s): No
  • Applications: General Purpose
  • Features: I²C, Latched Fault, UVLO
  • Programmable Features: Current Limit, Fault Timeout, Turn On Voltage
  • Voltage - Supply: 3.15V ~ 16.5V
  • Current - Output (Max): -
  • Current - Supply: 1.7mA
  • Mounting Type: Surface Mount
  • Package / Case: 10-TFSOP, 10-MSOP (0.118", 3.00mm Width)
  • Supplier Device Package: 10-MSOP
  • Feature Pins: ON, TIMER
  • Base Part Number: ADM1178
  • detail: Hot Swap Controller, Monitor 1 Channel General Purpose 10-MSOP
