دیتاشیت AD9652BBCZ-310
مشخصات دیتاشیت
| نام دیتاشیت |
AD9652
|
| حجم فایل |
1447.077
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
36
|
مشخصات
-
Manufacturer:
Analog Devices Inc.
-
Series:
-
-
Packaging:
Tray
-
Part Status:
Active
-
Number of Bits:
16
-
Sampling Rate (Per Second):
310M
-
Number of Inputs:
2
-
Input Type:
Differential
-
Data Interface:
LVDS - Parallel
-
Configuration:
S/H-ADC
-
Ratio - S/H:ADC:
1:1
-
Number of A/D Converters:
2
-
Architecture:
Pipelined
-
Reference Type:
External, Internal
-
Voltage - Supply, Analog:
1.8V, 3.3V
-
Voltage - Supply, Digital:
1.7V ~ 1.9V
-
Features:
Simultaneous Sampling
-
Operating Temperature:
-40°C ~ 85°C
-
Package / Case:
144-LFBGA, CSPBGA
-
Supplier Device Package:
144-CSPBGA (10x10)
-
Mounting Type:
Surface Mount
-
Base Part Number:
AD9652
-
detail:
16 Bit Analog to Digital Converter 2 Input 2 Pipelined 144-CSPBGA (10x10)
